16 AVENTICS | MSN | R499050100–BDL–001–AB
An excessively hard impact causes the
slide to rebound from the end position.
3. If hard impact of the slide is audible, stop
the trial run. A hard impact may be caused
if:
Ursachen für hartes Anschlagen können
sein:
– Mass moment of inertia of the moving
mass is too high
– Slide speed is too high
– No compressed air cushion on the
exhaust side.
4. Take corrective action for the above
causes.
5. When all the necessary corrections have
been made, repeat the trial run.
6. Conclude the trial run.
Finally mount the cylinder switches.
7

Dismantling and Repair

Exhaust the entire system and all devices.
CAUTION! Repair work on the slide guide is
not allowed!
8

Technical Information

See data in online/print catalog.
Subject to change without notice.
