Mounting with screws
00117683
The load must be mounted free from
distortion and stress-free on the slide.
Mounting screw "load" (1)
AVENTICS | MSN | R499050100–BDL–001–AB
3.4
NOTICE! The load must be placed on the slide
1
in such a way that the tilting moment of the
lever arm x is kept down.

Tilting moments of loads

m
00117684
m
00117685
13
