No. Description
1 ATX 12V Power Connector (ATX12V2)
2 ATX 12V Power Connector (ATX12V1)
3 2 x 288-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
4 2 x 288-pin DDR3 DIMM Slots (DDR3_A2, DDR3_B2)
5 Chassis Fan Connector (CHA_FAN4)
6 CPU Fan Connector (CPU_FAN2)
TM
7 V-Probe
8 Post Status Checker (PSC)
9 ATX Power Connector (ATXPWR1)
10 Vertical Type A USB 3.0 (USB3_9)
11 USB 3.0 Header (USB3_5_6)
12 USB 3.0 Header (USB3_7_8)
13 Chassis Fan Connector (CHA_FAN1)
14 SATA3 Connector (SATA3_0)
15 SATA3 Connector (SATA3_2)
16 SATA3 Connector (SATA3_1)
17 SATA3 Connector (SATA3_3)
18 SATA Express Connector (SATA_EXP0)
19 SATA Express Connector (SATA_EXP1)
20 SATA3 Connector (SATA3_A3)
21 SATA3 Connector (SATA3_A4)
22 SATA3 Connector (SATA3_A1)
23 SATA3 Connector (SATA3_A2)
24 SATA Express Connector (SATA_EXP2)
25 SATA3 Connector (SATA3_5)
26 SATA3 Connector (SATA3_4)
27 BIOS Selection Switch (BIOS_SEL1)
28 System Panel Header (PANEL1)
29 Direct Key Button (DIRKEY1)
30 XMP Switch (XMP_ON1)
31 Power Switch (PWR)
32 Reset Switch (RST)
33 Rapid OC Button (+) (PLUS)
2
(VOL_CON1)
