Pump type
DPK.V.65.80.15.2.5
DPK.V.65.80.15.4.5
DPK.V.65.80.22.2.5
DPK.V.65.80.22.4.5
DPK.V.80.80.37.2.5
DPK.V.80.80.37.4.5
DPK.V.80.80.55.2.5.0D
DPK.V.80.80.55.2.5.1D
DPK.V.80.80.55.2.5.0E
DPK.V.80.80.55.2.5.1E
DPK.V.80.80.55.4.5
DPK.V.80.80.75.2.5.0D
DPK.V.80.80.75.2.5.1D
DPK.V.80.80.75.2.5.0E
DPK.V.80.80.75.2.5.1E
DPK.V.80.80.75.4.5
Outlet flange
Note: For DPK and DPK.V only.
Note: Outlet flange need to be ordered as a separate accessory.
45 °
DN norm
flange
346
Z10 Z11 Z12 Z13
25 644 97 50
25 831 115 50
25 664 97 50
25 831 115 50
25 846 118 50
25 1003 108 50
25 1004 118 50
25 1003 108 50
25 1004 118 50
25 1003 108 50
4 x bolt size
PDC
Z14 Z15 Z16 ZDN1
46 200 250 80
46 200 250 80
46 200 250 80
46 200 250 80
46 200 250 80
46 200 250 80
46 200 250 80
46 200 250 80
46 200 250 80
46 200 250 80
Outlet flange Holes for bolts
DN 50
DN 80
DN 100
DN 150
Weight
ZM
[kg]
4 x M16 x 200 58.6
4 x M16 x 200 75.5
4 x M16 x 200 62.6
4 x M16 x 200 78.5
4 x M16 x 200 79.9
4 x M16 x 200 116.1
4 x M16 x 200 107.4
4 x M16 x 200 107.5
4 x M16 x 200 113.3
4 x M16 x 200 111.4
4 x M16 x 200 120.7
4 x M16 x 200 114.6
4 x M16 x 200 119.7
4 x M16 x 200 118.7
4 x M16 x 200 118.5
4 x M16 x 200 130.0
PCD
[mm]
4 x M10 92
4 x M12 130
4 x M16 165
4 x ∅23
230
