66 AVENTICS | CD01-PI | R412012449–BAL–001–AD
Device Description
5.1.4

Valves

The valves direct the air to the pneumatic drives. The electrical
and pneumatic connection is performed via a base plate.
30
Fig. 5: Plug-in valves, single and double solenoid
30 Single solenoid valve
31 Double solenoid valve
31 32
32 Pilot valve
33 Electrical connection
33
