Reversing
• By actuating the reversing button, the
indicator below lights up and an
acoustic signal is emitted.
Notice:
When reversing in working operation, the
supply of the cleaning solution will be inter-
rupted. The squeegee will not be lifted.
Moving the machine (in the case of a defect)
Notice:
Generally, the machine should only be
moved in pairs.
Attention:
Due to the high weight, manual movement
of the machine is risky!
Missteps can lead to personal injury and
damage to the machine.
• Movement is only possible when the release button is
pressed. (See page 95)
Brush installation
Before inserting, please check:
• that the brush does not fall below the red marking (bristles)
or 1cm of bristle length.
• the pad for wear and cleanliness before use.
Attention:
Do not use brushes which have reached
their wear limit. The wear limit is indicated
by the length of the red bristle. Do not use
worn or contaminated pads. Use original
TASKI brushes only. Failure to observe
these instructions may result in inade-
quate cleaning results or even floor dam-
age.
• Position the tools under the brush unit.
• Press the Brush drive ON/OFF but-
ton.
The brush unit will be lowered auto
matically; the tools will be engaged
and stopped.
Attention:
Check whether the brushes are engaged.
• The brush drive is activated by pressing the gas pedal.
Squeegee assembly
• The machine must be switched off.
• Position the squeegee (2) below the
1
2
1
2
• Push the squeegee upwards to latch
• Press the position locks together and
Filling the fresh water tank
Attention:
Max. permissible water temperature
60 °C/140 °F.
Diversey recommends using cold water
since hot water will adjust to the floor tem-
perature as soon as it is in contact with the
floor. Thus there are no advantages to us-
ing hot water.
• The machine must be switched off.
• Open the tank lid.
• Take the dosing cup from the fresh water tank.
• Pull the filling hose with watercou-
-
• Fill the fresh water tank with water.
Fill fresh water tank with Aquastop filter (optional)
• Connect a water hose to the Aquas-
• Fill the fresh water tank with water.
squeegee holder (1).
the squeegee holder.
insert the suction hose into the desig-
nated opening.
pling out of the fresh water tank and
connect it to a water tap.
top filter.
