Start-up protocol
1. Customers address:
2. Plumbers address:
3. Type of building
Single-family house
2-family house
Multi-family or Trade building
Public building
others
4. Type of appliance:
Order-No:
Date of manufacturing:
Manufacturing-No:
5. Type of Collector Installation:
Corrugated roof
Pantile roof
Flat roof
Wall
other type of installation
6. Installation in accordance to the Stiebel Eltron
Installation Instructions:
Are the flat collectors built in the stand in their
proper position and secured free of play with the top
and the bottom screws?
Has the installation of the pipework between the
collectors and the SOKI been performed in accordance
with the Stiebel Eltron installation example?
Has the pipework been hard-soldered with the solders
CP105 or CP203 without flux?
30
horizontal vertical
horizontal vertical
horizontal vertical
horizontal vertical
Place, Date
Have the safety valve (6 bar) and the vent been installed
in accordance with the installation example?
Was the pressure test performed with H -30 L or
H -30 LS at 7.8 bar?
Is the circuit of the heat-transfer medium filled and vented
using only the H -30 L or H -30 LS heat-transfer medium
at 3,5 bar?
Is a collecting pan for the H -30 L or H -30 LS
heat-transfer medium installed at the safety valve?
Are the shut-off valves open, and is the non-return valve
activated (pump-group assembly instructions)?
Is the collector temperature sensor mounted at the
specified position and electrically connected?
7. Control:
SOM 6 plus / SOKI plus
SOM 7 plus / SOKI 7 plus
SOM 6/3 D
SOM 8
SOM SBK
other control
Has the electrical wiring been performed in accordance
with the Stiebel Eltron wiring diagram?
Is the solar control set according to the installation and
operating instructions?
Has the test run of the circulation pump
been performed?
8. DHW circuit:
Has the solar storage system been installed to the
water mains in accordance with the Stiebel Eltron
installation example and the appropriate regulations?
Has the temperature sensor in the solar storage system
been mounted and electrically connected in accordance
with the Stiebel Eltron installation example?
9. Potential Equalisation and Lightning Protection
Is the pump-group connected to the existing
potential equalisation line?
Was the lightning protection equipment connected
by authorised skilled personnel?
Plumbers signature
