2.5
Accessories
2.5.1 Fixing accessories
Item
R1 mounting frame for one collector on end.
Installation on tiled roofs is possible with the
BP fixing set.
R2 mounting frame for two collectors, on end.
Installation on tiled roofs is possible with the
BP fixing set.
BP fixing set for mounting on a tiled roof.
RV frame connection set for joining several
mounting frames in installations on end.
2.5.2 Solar heating system accessories
Item
Stainless steel corrugated hose for the roof outlet/duct (2 hoses)
SOKI plus, solar compact installation
SOKI 6 plus, solar compact installation with integral SOM 6 plus control unit
SAS SOKI, cylinder connection set for SOKI plus, SOKI 6 plus and SOKI 7 plus
SOKI SBK-M, solar compact installation for solar heating combi cylinder SBK 600/150
SOM 8, comfort control unit
Collector sensor well, 1 pce. per control unit
H - 30 L, heat transfer medium, 10 litre can
H - 30 L, heat transfer medium, 20 litre can
Expansion vessel 18 litres
Expansion vessel 25 litres
Expansion vessel 50 litres
KS 150 SOL, wall mounted cylinder for DHW heating
SBB 300 plus, freestanding solar cylinder for DHW heating
SBB 400 plus, freestanding solar cylinder for DHW heating
SBB 600 plus, freestanding solar cylinder for DHW heating
SBK 600/150, solar heating combi cylinder
SBP 700 E SOL, buffer cylinder
2.6
Installation
The solar heating system must
!
only be filled with H - 30 L or
H - 30 LS heat transfer medium to provide
protection against frost and corrosion.
If more than 30 collectors are grouped
together to form a hydraulic assembly,
the type-test qualification is invalidated.
An individual inspection is required for
larger systems.
Commercial systems, the open content of
which exceeds 10 litres and is not more
than 50 litres (6 to 30 collectors), require
notification to the relevant local authority
[in Germany
check local regulations].
–
22
Standard delivery
2 x profile rails, 4 x locking brackets, 1 set of nuts
and bolts M 10 (SW 15/17)
2 x profile rails, 8 x locking brackets, 1 set of nuts
and bolts M 10 (SW 15/17), 1 x compensator with
air vent screw, 2 x gaskets
2 x roof hooks, 1 x collector strip, 1 set of nuts,
washers and bolts M 10 (SW 15/17), 6 x washers
2 x frame connectors, 1 set of nuts and bolts M 10
(SW 15/17), 1 x compensator with air vent screw,
2 x gaskets
Pipework installation
The pipes for flow and return lines must be
made of copper or stainless steel or should
be corrugated stainless steel hoses.
Recommended pipe diameter
- up to 4 collectors:
The pipes routed to the interior of the building
are to be provided on site. Ventilation tiles
are recommended as roof ducts for tiled
roofs with more severe inclination; for flat
and corrugated roofs with lesser inclinations,
routing the pipes through an external wall
is recommended. Avoid sawing off pipes
(swarf). It is advisable to use a pipe cutter
for swarf-free cutting. The pipes installed
should be connected to an earthing system
in accordance with current regulations. All
pipes must be connected to the building
earthing system via a short connection.
Soldered lines
Soldered lines must be brazed. Please
follow DVGW Code of Practice GW 2 when
carrying out this work. The solder used must
Part no.
comply with DIN EN 1044: CP105 and CP203
22 13 34
are both used without flux. Only gunmetal
and brass fittings are to be soldered using
flux F-SH-1 in accordance with DIN 8511.
22 13 35
Other flux would have a detrimental effect
on corrosion resistance.
22 13 36
Alternative lines
Appropriate sealant must be used on lines
18 56 60
using threaded locking ring fittings, press
fittings and corrugated hoses. The seals
must be resistant to glycol and temperatures
up to 180 °C.
Roof outlet/duct
Two flexible stainless steel corrugated
tubes that can be mounted on the threaded
collector connections or collector sensor
Part no.
well with flat packing and union nuts are
used to connect the collector array to the
07 34 69
pipework installation. These roof outlets/
22 04 58
ducts are equipped with factory-fitted
22 04 59
thermal insulation that is resistant to
22 04 63
temperature and UV.
07 42 43
07 43 50
18 53 07
07 32 21
07 32 22
07 40 30
07 40 31
18 78 68
07 40 98
18 78 73
18 78 74
18 78 75
07 40 67
18 54 60
Ø 18 x 1
