6. Priority of settings

The external forced-control signals will influence the settings available on the
pump control panel and with the R100. However, the pump can always be
set to max. curve duty or to stop on the control panel or with the R100.
If two or more functions are activated at the same time, the pump will operate
according to the setting with the highest priority.
The priority of the settings is as shown in the table:
Priority
1
2
3
4
5
Example: If the pump has been forced to stop via an external signal, the
pump control panel or the R100 can only set the pump to max. curve.
10
Possible settings
Pump control panel
or R100
Stop
Max. curve
–
Min. curve
Setpoint setting
External signals
–
–
Stop
–
–
