➢ Empty oil from gearbox and engine into an appropriate tank and hand it in at a collection point
➢ Dismount plastic and coloured metals.
➢ You are required to carry out the disposal of the dismantled machine remainder and dismounted parts, following national waste laws and
regulations.
2.5.9

Instructions for ordering spare parts

This user manual does not include a list of spare parts. The latest version of our catalogue can be downloaded from our web pages. If you do not have Internet
access, you can order the catalogue in printed form (against COD). In order to identify your machine properly you need to know its Type, Identification Number
(In°) and Order Number (CN°). These are given on the nameplate of your machine in the box, or in the warranty certificate. It is only possible to find proper
spare part designation with this information.
Tab. 9: Nameplate - example
2.6

Manufacturer address

VARI,a.s. Phone:
Opolanská 350 Fax:
Libice nad Cidlinou
289 07 Czech republic E-mail:
Web:
2.7

Picture appendix

The picture appendix is common for all the language versions. You can find it at the end of this manual in the Chapter Pictures.
1) Place for holding at the back (frame U-tube)
2) Screen holder
3) Dismounted disc cover
4) Place for holding the machine at the front(cutting disc)
5) Tilted handlebars in the package (transport position)
Pict. 1: Unwrapping the machine
1) Disc drive clutch level
2) Wheel drive clutch lever
3) Handlebars fastening bolt
4) Accelerator lever (gas lever)
5) Side screen fastening bolt
6) Side screen
7) Cutting disc
8) Blades (4 pieces)
9) Disc cover according to the EN 12733 standard
Pict.2: Description of the main parts
67 Collection point information is given by responsible local office.
26
Field
Type
N°
CN°
(+420) 325 607 111
(+420) 325 607 264
(+420) 325 637 550
vari@vari.cz
http://www.vari.cz
6) Bag
7) Dismounted left and right disc cover
8) Middle cover (fixed-mounted to the machine)
9) Left cover
10) Right cover
11) Side and rear screens
10) Disc cover
11) Frame - tube
12) Handle
13) Engine
14) Fuel tank lid
15) Wheel
16) Gearbox cover
17) Safety lock button
18) Stirrup with wires
67 .
Description
Machine type designation:
BDR-620D
Unique manufacturer identification number.
1003901016.0110.00001
(product.month-and-year.consecutive-number)
Business (order) number:
4264
