Safety pictograms

The user is required to keep the machine pictograms readable, and have them exchanged in case they are damaged.
Locations:
Combined sticker, which is stuck to
the rear plastic cover. (Pict.17)
Separate sticker on the front plastic
cover. (Pict.18)
Sticker (Pict.20) on the control
lever (1) on the right handle
(Pict.2).
Sticker (Pict.19) on the control lever
(2) on the left handle (Pict.2).
Sticker (Pict.21) placed on the
cutting disk cover on the left side in
the direction of movement.
Tab. 3: Safety pictograms
2.3

Basic information

2.3.1

Machine use

This brush cutter BDR-620D, DR-620DB is intended for mowing of high thin-stalk grass stands and woody underbrush
the maximum height of 80 cm on maintained areas.There must be no solid objects in the stands or extensive surface unevenness. The brush cutter is not designed
for park grass stand care.
The use of this machine for purposes other than those it was designed for is then considered as unauthorised use!
The machine can work at all the tilted positions described by the engine manufacturer provided that the attendant is able to lead it safely for both him and his
surroundings.
Protective devices meet the requirements of ČSN EN 12733 and EN 12733 standards. These standards focus primarily on the attending persons' safety, as they
can be hit by stones and other subjects flying from the machine rotary system. Therefore, the attending person must always be in normal operating position, i.e.
behind the machine, holding the handlebars firmly with both hands.

It is forbidden to remove any protective devices and covers from the machines.
2.3.1.1

Technical information

BDR-620DD
Length
Width (including the side screen)
Height
Weight
Maximum cutting width
Safe climbing ability
Cutting disk revolutions 47
Maximum blade circumferential velocity
Travelling speed
Area capacity
48
Gearbox oil capacity
Gearbox oil quality
Tab. 4: Technical information for BDR-620D, BDR-620DB
46 The brush cutter is not intended for cutting woody underbrush thicker than 5 mm! If you don't follow this principle, you damage the machine.
47 Actual rpm. of the disc when not cutting, including belt transmission losses.
48 Square meters cut per min./hour will vary, depending on the type of the stand.
Number: Description:
(1) Study the user manual before operating the machine.
(2) Spark plug cable must be disconnected during machine maintenance.
(3) Do not reach with your arm nor step with your leg into the cutting blade work space – risk of cutting.
(4) Risk of injury from chippings, cut-offs, flying objects, etc. Other persons and animals - keep safe distance
from the machine.
(5) Adhere to the machine's maximum safety climbing ability when working.
(6) Guaranteed sound power level of the machine.
- Tool turning direction arrow – to the right (clockwise)
Starting the cutting disc drive: „0" = the cutting disc is not rotating, „1" = pushing the safety lock button,
-
„2" = the cutting disc is rotating
- Turning on the machine wheel drive. „0" = the machine is standing still, „1" = the machine is moving
- Area forbidden for other persons and animals. Minimum safe distance from the machine.
Unit BDR-620D
mm
mm
mm
kg 67
cm

min -1
m.s -1
km.h -1
m .h
2 -1
l (litre)
API
SAE
BDR-620D, BDR-620DB
46 in a wood and on a meadow up to
BDR-620DB
1730
823
1191
66
62,2
10°
1964
64
2,0 - 2,8
1224 - 1680
0,025
GL-4 (GL-5)
90 (80W-90)
19
