COMBICONTROL
seconds
rc.01
This parameter displays the seconds in a range of 0...59. Writing on this parameter ad-
justs the seconds.
date
rc.02
This parameter displays the date in a DD-MM format. Writing on this parameter adjusts
the date.
rc.03
year
This parameter displays the year in four digits. Writing on this parameter adjusts the year.
rc.04
data valid
The real-time clock is running for approx. 30 days after switching off the supply. After this
it must be adjusted again. If this parameter has the value „false", the date and/or time is
not correct. The clock must be adjusted.
6.3.4 Process image
pi.00
inputs
Displays the condition of the local inputs.See section in-/output module. Set 0 displays
the first word, set 1 displays the second.word, etc.
pi.01
outputs
Displays the condition of the local outputs.See section in-/output module. Set 0 displays
the first word, set 1 displays the second.word, etc.
pi.02
axis indata 1
Displays the value of the first process-input data (32 Bit) of the axes. Set 0 is for the data
of axis 1, set 1 for the axis 2, etc.
pi.03
axis outdata 1
Displays the value of the first process-output data (32 Bit) of the axes. Set 0 is for the
data of axis 1, set 1 for the axis 2, etc.
pi.04
axis indata 2
Displays the value of the second process input data (16 Bit) of the axes. Set 0 is for the
data of axis 1, set 1 for the axis 2, etc.
pi.05
axis outdata 2
Displays the value of the second process-output data (16 Bit) of the axes. Set 0 is for the
data of axis 1, set 1 for the axis 2, etc.
pi.06
axis indata 3
Displays the value of the third process-input data (16 Bit) of the axes. Set 0 is for the data
of axis 1, set 1 for the axis 2, etc.
GB - 26
Address
0401h
Address
0402h
Address
0403h
Address
0404h
Address
0500h
Address
0501h
Address
0502h
Address
0503h
Address
0504h
Address
0505h
Address
0506h
