COMBICONTROL
Ethernet interface
Type
Connector
Speed
Use
Serial interface
Type
Connector
Speed
Use
Memory of the programming system
Code
Data
Retain
Flag area
Input
Output
1.6
Accessories
Operators
F5 HSP5/485, screw terminal
F5 HSP5/485, RJ45
Supply cable
Cable RS232 for COMBIVIS
Cable RJ45 open end (for operator -9001), 2,5 m
Patch cable RJ45 (for operator -9002), 5 m
GB - 6
09C5xxx-xxxx
IEEE 802.3
10Base-T
RJ-45, 8-pole, screened
10 MBaud
Connection to CoDeSys (programming sys-
tem, debugging, visualization)
Connection to COMBIVIS (control and axis
adjustment, Scope)
Connection to any devices (Socket-APi)
09C5xxx-xxxx
DIN66019II, RS232
D-Sub 9 female
9,6...115,2 kBaud
Connection to COMBIVIS (control and axis
adjustment, Scope)
Connection to any devices (COM-APi)
09C5xx-xxxx
256 KByte, double for
online change
392 KByte
31 KByte
512 Byte
256 Byte
256 Byte
19C5xxx-xxxx
IEEE802.3
10/100BaseTx
10/100 MBaud
autocrossover
19C5xxx-xxxx
DIN66019II, RS232,
RS485 full/half duplex
19C5xx-xxxx
8 MB, double for onli-
ne change
12 MB
31 KB
32 KB
2 KB
2 KB
Material number
00F5060-9001
00F5060-9002
Material number
0058025-001D
00F50C3-2025
00F50C3-1050
