Pressure Calibrator
LPC 200
Specifications
Pressure connection
Material wetted parts
Internal transmission fluid
Permissible temperature
ranges
- Medium
- Storage
Housing
Electrical connection
Ingress protection
Mass
CE-conformity
1) Calibration data sets for up to 10 transmitters can be stored in each LPC 200
*) Calibrated at 3 °C and in vertical mounting position with pressure connection facing downwards.
{} Items in curved brackets are optional extras for an additional price.
LR-Cal Operating Instructions
LPC-2 Reference Pressure Sensor
≤ 1000 bar: G ½ B; {various connection adapters on request}
> 1000 bar: M16 x 1.5 female, with sealing cone
Stainless steel (pressure range > 16 bar additional Elgiloy
Synthetic oil (only for pressure range up to 5 bar)
°C -30 ... +105
°C -40 ... +85
Stainless steel
round plug, 8-pole
IP65 (with cable connected)
g approx. 0
89/336/EWG Interference emission and immunity to EN 61 36;
97/3/EG Pressure equipment directive (Module H)
Pressure Calibrator LPC 200
