Pressure Calibrator
LPC 200
Extreme temperatures have an adverse effect on battery charging. As a result,

the battery may first need to be either cooled or warmed, as appropriate.
When the battery is nearly empty, the message "low BAT" appears in the display.

With 0 % battery level, the equipment automatically switches itself off and must
then be recharged using the battery charger.
Do not use a damaged or worn battery charger.

Keep the equipment between 15 °C and 35 °C.

Equipment with either a warm or a cold battery might not operate fully.
In particular, Li-Ion rechargeable batteries operate poorly under 0 °C.


3. Connection of LPC-2 reference pressure sensors

Only use LPC-2 Series sensors! Using other sensors can
damage both the LPC 200 and the sensors. Switch the
instrument off before changing sensors. Unless the sensor is
properly connected before the equipment is switched on, it
may not be correctly identified by the instrument.
For Gauge-Pressure sensors, there is a pressure-equalising
vent in the top of the sensor under the plastic fitting. This vent
(with integrated membrane) must remain absolutely clear!
Only use original LR-Cal connection cable for the operation of
LPC-2 Pressure Sensors.
LR-Cal Operating Instructions Pressure Calibrator LPC 200
GB
11
