INSTALLATION AND OPERATION MANUAL
KESSEL - Aqualift F Compact wastewater lifting
station for installation in a concrete slab/floor
For wastewater with and without raw sewage
Order Number 28701 (Single pump), 28704 (Twin pump)
Installation
This system was installed and commissioned by the following
service company:
Name / Signature
Edition 2017/06
Illustration shows Art. # 28704
Commissioning Training
Date Location
Product Advantages
■ For installation in a concrete
slab/floor
■ SDS (Self Diagnosis System)
control unit
■ Pressure sensor for accurate
monitoring of wastewater levels
■ Seal connection flange for
installation in waterproof
concrete floors
■ Integrated floor drain
function
■ Modifiable from single to twin
pump system
■ Easy plug in cable to control
unit
85101 Lenting
Z 53.2 484
Company stamp
ID-Number 010-561
