Configuring the matrix switch
6. Use the
Interface A
graphs to enter the following data.
Operational
mode:
IP address:
Netmask:
Connection type:
7. Press to save your settings.
F2

Configuring global network settings

Global network settings ensure even in complex networks that the matrix switch is
available from all sub networks.
How to configure global network settings:
1. Use a user module to press the
display of the KVM matrix system.
2. Press to call the Configuration menu.
F11
3. Select the Network
4. Enter the following data to the
Global
preferences:
Hostname:
Domain:
Gateway:
DNS Server 1:
DNS Server 2:
5. Press to save your settings.
F2
8 · G&D CompactCenter X2
« Matrix switch
(Network A interface) or
Press F8 to select the operational mode of the
work B interfaces:
 Off: switches off network interface.
 Static: uses static settings.
obtains the settings from a DHCP server.
 DHCP:
Enter the IP address of the interface .
No inputs are possible in the DHCP operational mode.
Enter the netmask of the network.
No inputs are possible in the DHCP operational mode.
Press to define if the connection type is to be negotiated
F8
with the remote device (
Ctrl+Num
row and press Enter
Main Network
Press F8 to select the operational mode:
 Static: uses static settings.
obtains the settings from a DHCP server
 DHCP:
Enter the hostname of the matrix switch.
Enter the domain the device is to belong to.
Enter the gateway IP address.
Enter the DNS server IP address.
Optionally, enter the IP address of another DNS server.
(Network B interface) para-
Interface B
Auto ) or select one of the listed types.
(default) hotkey to open the on-screen
.
paragraph:
Network A or Net-
