Installation Instructions CP-5412/Windows NT
Further
Requirements
74
To operate the module with the software, a free memory area of 16
Kbytes is required
The CP 5412 (A2) uses one of the following interrupts:
Possible Interrupt
Numbers
These settings are only made when the software is installed and are
described in detail in the software description.
The following table shows the default interrupt assignment of a com-
puter:
Interrupt Belegung
IRQ 5 Sound card , MPI cards
IRQ 10 Network adapters, SCSI controller
IRQ 12 PS2 mouse
IRQ 15 Hard disk controller, SCSI controller
If all the possible interrupts are being used by the hardware listed
above, you will have to reassign hardware components (driver software
of the manufacturers) or remove unnecessary hardware or disable it in
the BIOS.
5 10 11
Installationsanleitung CP-5412/Windows NT
C79000-B8274-C375-02
12 15
