Installation Instructions CP-5412/Windows NT
Settings for
STEP 5
62
The defaults were not intended for operating STEP 5 via the
CP 5412 (A2). Please use the following settings for communication
with STEP 5:
Parameter
Transmission rate
Highest station address
When assigning parameters to the module, the access point of the
application "CP_L2_1:" must be assigned to the module CP 5412 (A2)
(PROFIBUS)" for STEP 5 operation.
Value
187.5 Kbps
31
Installationsanleitung CP-5412/Windows NT
C79000-B8274-C375-02
