Selecting the I/O
Range
Installationsanleitung CP-5412/Windows NT
C79000-B8274-C375-02
The following table shows the assignment between the switch setting
and the selected I/O range:
Switch Setting
1 2 3 4
0 0 0 0
0 0 0 1
0 0 1 0
0 0 1 1
0 1 0 0
0 1 0 1
0 1 1 0
0 1 1 1
1 0 0 0
1 0 0 1
1 0 1 0
1 0 1 1
1 1 0 0
1 1 0 1
1 1 1 0
1 1 1 1
The selected I/O range must not be used by any other card!
Installation Instructions CP-5412/Windows NT
240
244
248
24C
280
284
288
28C
300
304
308
30C
390
394
398
39C
I/O Range
(hex.)
243 (standard)
H - H
247
H - H
24B
H - H
24F
H - H
283
H - H
287
H - H
28B
H - H
28F
H - H
303
H - H
307
H - H
30B
H - H
30F
H - H
393
H - H
397
H - H
39B
H - H
39F
H - H
