Installation Instructions CP-5412/Windows NT
Procedure for
Software
Configuration
60
After hardware configuration, you automatically return to the "Access
Path" tab in which you can configure the software.
Follow the steps outlined in the table below in the "Access Path" tab
page:
Step
1 Select an access point in the "Access Point of the
Application" list box.
If you select "<Add/Delete>", you can also create a new
access point.
2 Select a module parameter set in the "Interface parameter
assignment used" list box.
3 Configure the selected module parameter set with the
"Properties" button.
4 Repeat steps 1, 2 and, if necessary, step 3 for further
access points.
5 Close the configuration program.
• Save your assignment with OK,
• Discard new assignments without saving with Cancel.
If no access point was assigned to the module, it is not
possible to operate the module.
The configuration program proposes the default device name
CP_L2_x: - x is the number of the CP = 1, 2, ...
If you use the DP programming interface, this default must not
be modified since the DP libraries use this ID as standard.
CP_L2_x must be allocated to the CP 5412 (A2) (PROFIBUS).
For further information about the configuration, use the Help function
of the selected configuration program.
Procedure
