KEB COMBIVERT F1 Betriebsanleitung Seite 54

Connection Size 16...23
Connection Size 16...22
GB
Provide suitable protective measures for
the operation of the frequency inverter!
Connection Size 23
L1
L2
L3
PE
Line:
95 mm
E 18
Install the braking resistor fire-resistant and safe from touch!
L1
L2
L3
PE
Lay control and power lines separately!
Operate unit size 23 only with line reactor!
Line Reactor
U1 U2
V1 V2
W1 W2
Line:
50 mm 2 /
2
max. 3 m
Lay control and power lines separately!
The combination with frequency inverters allows only restricted use of standard
fault current (FI) - protective switches.
Neutralization as protective measure is prohibited at the output of the inverter,
see chapter Operating Specifications Fault Current Protective Switch!
The KEB COMBIVERT/COMBIDRIVE is designed for fixed connection, refer
to chapter Operating Specifications Connection Instructions!
Measures for radio interference suppression and interference suppressions
are listed in chapter Operating Specifications Interference Suppression!
PA PB
L1
L2
+
L3
PE
Charge
Control Circuit
+
Ð
L1
L2
+
L3
PE
Charge
Control Circuit
Option (only for unit groups F1-K / F2)
Use the shortest possible
twisted cables!
U
V
M
W
~
3
PE
For protective measures against
radio interference connect the
shield to both sides! In case of
low-frequency
suppress the
according to VDE 0160!
U
V
M
W
~
3
PE
For protective measures against
radio interference connect the
shield to both sides! In case of
low-frequency
suppress the
according to VDE 0160!
interferences
interference
interferences
interference
