Radio Interference Suppression Filter - KEB COMBIVERT F1 Betriebsanleitung

Accessories: Radio Interference Suppression Filter
Radio Interference The frequency inverter KEB COMBIVERT/COMBIDRIVE exceeds the interference suppression
Suppression Filter limits set up in EN 55011. It causes mains-restricted interferences and malfunctions due to radiation
from the frequency inverter, the motor and the lines. All unit sizes of KEB COMBIVERT/COMBIDRIVE
can be supplied optionally with radio interference suppression filters.
Unit group
Technical Data
Part No.
00.90.415-4249
00.90.415-4259
00.90.415-4269
00.90.415-4279
00.90.415-4289
1)
external radio interference suppression filter only for unit group F2
I Rated current
N
Dimensions
E
Installation – The use of shielded control and motor cables and the twisting of the lines of the braking options prevents
malfunctions caused by radiation from the lines. The shielding for the cables must be applied to both
sides over a large contact surface!
– Lay the cables parallel with a minimum distance of 20 cm between control cable and power cable to
prevent any interference coupling. In the event power and control cables cross each other they should
be layed in an angle of 90° to each other.
– To prevent interferences due to radiation from the frequency inverter which affect adjacent devices
install KEB COMBIVERT/COMBIDRIVE and the filter inside a steel cabinet. Place external filters as
close as possible to the inverter.For the installation of KEB COMBIVERT/COMBIDRIVE and filter inside
a steel cabinet connect the earthing over a large contact surface (e.g. mounting plate of control cabinet).
Removing any existing paint between the components ensures an area contacting. The earthing shall
be connected point-to-point starting at a central earthing point.
Unit size
F1-K / F2 13...22
F1-p 14...23
F2 23...27
F1-P 24...28
Unit size
23 1) /24
25
26
27
28
U Rated voltage
N
A
D

Radio interference suppression filter

The radio interference suppression filters are installed in the
housing of the frequency inverter and internally connected.
Installation and connection of the internal radio
interference suppression filters is exclusively done
in the factory.
The interference suppression filters are externally installed
in the switch cabinet
I [A]
N
180 3 x 400 V
210 3 x 400 V
250 3 x 400 V
300 3 x 400 V
370 3 x 400 V
Part No. A
C
External Filter
00.90.415-4249 758
00.90.415-4259 758
00.90.415-4269 775
00.90.415-4279 775
00.90.415-4289 1200 600
B
ANTRIEBSTECHNIK
U
N
B C D E
203 173 660 160
203 173 660 160
203 195 660 160
203 195 660 160
250 1060 400
GB
Fixing
Bore
8.5
8.5
8.5
8.5
11
E 35
