Owner's Guide

Caution: Federal law restricts this device to sale by or on the order
of a dentist.
Congratulations...
...on your purchase of the Coltolux
is designed for intra- and extra- oral polymerization of visible-light-cured
dental materials with Camphorquinone (CQ) Photoinitiators.
See Figure 1 and Figure 2 for component recognition.
Fig. 1.
a. Handpiece
b. Handpiece Charger Base
c. Activation Button
Fig. 2.
d. Voltage/Serial Number Label
e. Power Cord with Power Supply
f. Plug Adapters (Export Only)
g. Light Shield
h. Test Block
i. Barrier Sleeves
j. Light Lenses
Please take special note of the safety precautions below.
I. SAFETY PRECAUTIONS
A. Observe the following precautionary procedures before
and whenever using the Coltolux
CAUTION: Before connecting, read all instructions.
CAUTION: Light output from this unit may be a significant
increase compared to other polymerization devices; therefore,
when using this curing light:
• Determine curing time of your material using the enclosed
test block.
• Adjust curing techniques in accordance with the increased
energy.
CAUTION: Do not operate the Coltolux
lens in place and fully seated on the unit (Fig 4).
WARNING: Do not substitute the light lens from other
curing lights. Use only the light lens supplied for this unit.
Never use components not designed for use with this device
since this may impair performance.
WARNING: Do not refrigerate or put in freezer to cool.
WARNING: Use of a power supply other than that listed
in section XIV. Accessories may result in increased
electromagnetic emissions and/or decreased electromagnetic
immunity.
CAUTION: Persons having a history of photosensitive
reactions or who are using photosensitizing drugs should
not be exposed to light from this unit.
B. All high intensity lights may cause retinal damage with prolonged
exposure to the eyes, therefore we urge you observe these
cautionary statements:
CAUTION: Never look directly into the light emitted from
the light lens or reflected from tooth or other surfaces.
• Patients, operators and dental technicians should always use
proper eye protection.
• Always use light shields (Cat. No. C7990) available for light curing
or use eye protection goggles (Cat. No. C7988) that block light in
the blue spectral range. Sunglasses are not adequate protection.
® ®
LED Curing Light. Coltolux
®
LED Curing Light:
® LED without the light
• A barrier sleeve should be used for every patient
(Cat. No. C7957). Slide the barrier sleeve over the handpiece
and then attach the light shield.
• Before each use, inspect the light lens (Section IX).
LED
CAUTION: The red indicator light on the handpiece
indicates the unit has entered thermal protection mode.
Action must be taken to allow the unit to cool.
See section V. Indicators.
CAUTION: The red indicator on the charger base indicates
a warning that the battery may not have sufficient charge
for proper curing operation and that action must be taken
to charge the battery.
II. UNPACKING
• Before unpacking, examine the carton for external damage,
and if severe, contact your shipper/carrier.
• Open carton and carefully remove the unit and accessories.
Make sure supply voltage is within the range specified on the
power supply (Fig. 3). If not, do not operate this unit;
contact your dealer or Coltène/Whaledent Inc.
III. SET-UP AND ASSEMBLY
®
• Coltolux LED is designed as a cordless handpiece unit
with a separate charger base. Place the charger base on
!
a smooth flat surface in an area that is dry and free of dust,
is convenient and has an outlet within easy reach of the
supplied power cord.
Export units include additional plug adapters (Fig. 2F).
Install the appropriate plug adapter onto the power supply
(Fig. 3):
• Remove the protective insert by first sliding the release button
in the direction indicated by the arrow. Hold the button in this
position while removing the insert from the supply.
• Angle the top of the new adapter into the recess of the supply.
Slide the release button in the direction indicated while
simultaneously pressing the new adapter into place.
Please Note: Additional plug adapters are not supplied for
Australian and New Zealand markets. Plug the power cord
into the wall outlet and then into the charger base. A green light
on the charger base indicates power is available to charge the

handpiece.

• Insert the handpiece into the charger base. When the handpiece
is being charged, the light on the charger base will be red. When
the handpiece is fully charged and ready, the red light on the
charger base will turn green.
The initial charging of the handpiece will require approximately
3 hours to fully charge.
• When the handpiece is removed from the charger base the
small light above the On/Off button on the handpiece will be
green, indicating the unit is ready for use. If the light does
not light up green, see Section VII Troubleshooting.
CAUTION: Never modify the power cord.
WARNING: Explosion hazard. Do not use in the presence
of flammable anesthetics.
IV. FUNCTION CHECK
A. Activate/Deactivate Light
Depressing the On/Off button on the handpiece activates or
deactivates the curing light (Fig. 1c). Do not hold the button
continuously throughout the curing cycle. During operation
an audible beep will be emitted every 10 seconds.
The unit shuts off automatically after 20 seconds.
3
