+ = anterior placement / – = posterior placement (in relation to the alignment reference line)
Item see fig. 7
Clearly mark the lateral socket reference point
point.
Position the tuberosity reference point
floor measurement.
CAUTION! The correct position and flexion of the prosthetic socket is crucial for the
safety of the patient and functionality of the prosthetic knee joint, and avoids premature
wear.
INFORMATION: The 4R118 Adapter Plate (max. body weight 125 kg) can be used for fur­
ther posterior placement.
Position the prosthetic socket so the lateral socket reference point
reference line
Adjust the socket flexion angle β depending on the hip flexion contracture (angle α) according to
the following specifications:
If the angle α = 0°, the optimum value of the angle β = 3 to 5° to the alignment reference line.
If the angle α > 0°, the optimum value of the angle β = α + 5 to 10°.
To fabricate the prosthetic socket for the 3R106-Pro=KD, observe the section "Fabricating the
prosthetic socket" (see Page 26).
Position the lamination anchor or socket adapter so that all prosthetic components between the
socket and prosthetic knee joint can be connected to each other correctly.
Join the prosthetic socket and the prosthetic knee joint using the adapters you selected.
Be sure to follow the adapter instructions for use during adjustment and installation.
Position the 743A80 50:50 Gauge on the anterior side of the prosthetic socket and mark a point
respectively in the distal and proximal area.
Using these points, mark the anterior centre line of the prosthetic socket.
Clearly mark the anterior socket reference point
centre line).
Position the prosthetic socket so the anterior socket reference point
ence line
Adjust the socket flexion angle γ according to the patient's adduction angle.
5.3.1 Shortening the Tube Adapter
CAUTION
Incorrect processing of tube
Fall due to damage to the tube
► Do not clamp the tube into a vice.
► For shortening the tube, use only a tube cutter.
Tools required:
>
719R3 Tube Cutter, 718R1 Tube Deburrer
1) CAUTION! The length of the tube must not be less than the required length for the
patient, since length compensation in the insertion area of the prosthetic knee joint is
prohibited.
Use the tube cutter to shorten the tube to the required length (see fig. 8).
2) Carefully deburr the inside and outside of the tube with the tube deburrer (see fig. 9).
3) Dispose of the remainder.
5.3.2 Installing the Tube Adapter
CAUTION
Incorrect mounting of the tube
Fall due to breakage of load-bearing components
Bench alignment process
.
.
30 mm proximal to the tuberosity reference
of the prosthetic socket at the height of the tuberosity-
(intersection of the socket edge and anterior
lies on the sagittal alignment
lies on the alignment refer­
