MANAGING POWER AMPLIFIERS

37
43
45
The LD OCS software offers the option to manage multiple LD DSP44K and DSP45K power amplifiers. Right click on the desired power
amplifier to access the edit menu of the power amplifier.
37
Ethernet Config – the Ethernet Config editing window provides network information, the facility to change the IP address of the power
amplifier, to enable DHCP, to reset the Ethernet module of the power amplifier (if supported by the network), to
name the power amplifier, and in the case of several connected amplifiers, to specifically identify one of them
(not with USB connection).
38
Network Information – network information.
39
IP Address – to manually change the IP address, disable DHCP (remove the checkmark), enter address and click pdate IP/DHCP.
To reset the Ethernet module of the power amplifier, click Reset Ethernet Module .
40
Device Name – enter a name (maximum 8 characters) into the input field and click Change Device Name.
41
Identify device – to identify a power amplifier, click Identify Device. The power amplifier's name and its IP address will be shown
briefly in the device display.
42
Reconnect Device – to restore a broken connection (e.g. after a power failure), click on Reconnect Device.
43
Add Virtual Device – a virtual power amplifier can be added under "Amplifiers" for the purpose of, for example, testing an amp preset
offline or creating a new one, To do this, click Add Virtual Device and select under LD series DSP44k.
This virtual power amplifier will be displayed as "offline" under Serial Number.
44
Delete Device – to remove a power amplifier from the list "Amplifiers", click Delete Device.
45
Rename Device – click on Rename Deviceto rename the power amplifier. Enter a name into the open input field
and click OK.
46
Identify device – to identify a power amplifier, click Identify Device. The power amplifier's name and its IP address will be shown
briefly in the device display.
Right-click on Amplifiers to access the editing menu.
47
Add Virtual Device – a virtual power amplifier can be added under "Amplifiers" for the purpose of, for example, testing an amp preset
offline or for creating a new one. To do this, click Add Virtual Device and select under LD series DSP44k.
This virtual power amplifier will be displayed as "offline" under Serial Number.
48
Add new Zone – creates a new zone.
49
Delete selected Zone – delete selected zone.
50
Rename selected Zone – rename selected zone.
37
38
39
42
44
46
40
41
47
48
49
50
