DISCLAIMER
In the event of operator error, improper use or negligent handling of the software, the manufacturer (Adam Hall GmbH does not accept any
liability for any damage to equipment of any kind or any software; personal injury included.

INTRODUCTION

The LD OCS software (Online Control System) enables you to configure LD DSP44K or DSP45K DSP amplifiers, load current LD speaker
presets and create and manage individual custom speaker and amp presets in 80 memory slots. The software is compatible with Windows
operating systems 7, 8 and 10 and requires either a USB interface (version 2.0 or later) or an Ethernet interface for data connection.

SOFTWARE INSTALLATION

Download the file LD_OCS_Setup.exe from the product page at WWW.LD-SYSTEMS.COM and install it on a Windows PC.

ESTABLISHING CONNECTION VIA USB

Connect the USB port of the LD DSP44K or DSP45K power amplifier to the USB port of your computer using a suitable USB cable (USB 2.0,
USB-A to USB-B) and switch on the amplifier (driver installation may take a few moments. IMPORTANT: Connect NO MORE THAN 1 power
amplifier via USB). Now start the LD OCS software and click on the magnifying glass icon with the plus symbol under Devices (Fig. 1). The
connected amplifier will be displayed with model number, name and serial number under Amplifiers (Fig. 2). You can now synchronize the
amplifier's current settings with the software by double-clicking on the power amplifier model (Fig.3).
