FREQUENCY RESPONSE (NOT LOGGED IN AS ADMINISTRATOR)

169 170
168
168
165
FREQUENCY RESPOSE – graphical representation of the frequency response. (Horizontal zoom in: right-click and drag right to mark
166
Grab point GAIN and FREQUENCY – click and hold the grab point to adjust the frequency and gain of the selected frequency band by
167
Grab points Q-FACTOR – click and hold a grab point to adjust the Q-factor of the selected frequency band by dragging horizontally as required.
168
Max/Min – use the arrow symbols to zoom vertically.
169
GAIN lock – click on the button to lock (red button) or unlock (grey button) editing of gain in the graphics window.
170
FREQ lock – click on the button to lock (red button) or unlock (grey button) editing of frequency in the graphics window.

MANAGING AMP PRESETS

In the overview window, click LIBRARY and then click Amp Preset. You can now import the amp presets previously saved on the PC (see item
29) into the list of presets (Open from disk) to create a separate library and save it as a whole in a file on the PC and transfer it to the amplifier.
171
20
the desired area. Horizontal zoom out: right-click and drag left to mark the desired area. Scroll vertically by
using Ctrl and the left mouse button)
Note: In order to be able to determine which channel the cursor follows as you hover above the graphics
(point 122), please log in as an administrator in the OCS software (point 15).
dragging horizontally or vertically.
172
173
174
167 166
175
176
177
165
167
178
