Editing windows for importing speaker measurement data from different measurement systems.
126
Import of measurement data.
127
Clear – delete measurement data.
128
Adjust Ref. Level – use arrow symbols to adjust level.

MANAGING CUSTOM PRESETS

In the overview window, click LIBRARY, then click Custom Speaker Preset. You can now import the custom speaker presets previously saved on
the PC (see item 37) into the list of presets (Open from disk) to create a separate library and save it as a whole in a file on the PC and transfer it to
the amplifier.
129
130
131
132
129
List of custom speaker presets (1 – 80).
130
Reset Preset – remove preset from list. Right-click the desired preset, then click on Reset Preset and confirm with Yes.
131
Open from disk – load preset into list from PC. Right-click on a free preset (empty). Click on Open from disk, select the desired preset
number in the memory of the PC and click Open.
132
Save to disk – save preset to the PC memory. Click with the right mouse button on the desired preset, click on
Save to disk, select a location, rename the preset as desired and then click Save.
133
Save Custom Speaker Library to Disk – save all presets in the list in a file on the PC. Click Save Custom Speaker Library to Disk,
134
Open Custom Speaker library from Disk – import a custom speaker preset library from the PC into the list of presets.
135
Send Custom Speaker Library to Amplifier – transfer currently loaded custom speaker preset library to the memory of the power amplifier.
136
Send selected Custom Spk. Preset to amp – transfer a preset from the list into the preset library of the power amplifier. Click to
select a location, name the library as desired and then click Save.
Click Open Custom Speaker library from Disk, select the desired file in the
PC memory and then click Open.
Click Send Custom Speaker Library to Amplifier. The process takes a few seconds.
highlight the desired preset, and then click Send Selected Custom Spk.
Preset to amp.
133
134
135
136
