Clock (12/24h, setting) and Tire diameter. Press + or - (10/12) to navigate to the desired selection.
Confirm the selection with the left toggle button (11).
• Changing the language option of the DS3 display
Go to the Menu screen / Setup. Select 'Language' by pressing the + and - button (10/12), and
confirm with the left toggle button (11). Press the + and - button (10/12) to select the desired
language. Press the left toggle button (11) to confirm the selection and to return to the previous
screen.
• Adjusting the screen or LED brightness of the DS3 Display / Remote
Go to the Menu screen / Setup. Select 'Brightness' or 'LED' by pressing the +
and - button (10/12), and confirm with the left toggle button (11). Press the +
and - button (10/12) to select the desired screen or LED brightness level. Press
the left toggle button (11) to confirm the selection and to return to the previous
screen.
• Changing the Units
Go to the Menu screen / Setup. Select Units by pressing the + and - button (10/12), and confirm
with the left toggle button (11). Press the + and - button (10/12) to select the desired Unit. Press
the left toggle button (11) to confirm the selection and to return to the previous screen.
• Adjusting the Clocks
Go to the Menu screen / Setup. Select Clock by pressing the + and - button
(10/12), and confirm with the left toggle button (11). Press the + and - button
(10/12) to select between 12 or 24 hour notification. Press the left toggle
button (11) to confirm the selection and to jump to the next field.
In first field, press the + or - button (10/12) to correct the hour. Press the left
toggle button (11) to confirm the selection and to enter the next field. Repeat
these steps for the next four fields.
• Changing the Start screen
Go to the Menu screen / Setup. Select 'Start screen' by pressing the + and - button (10/12), and
confirm with the left toggle button (11).
• Changing the Tire diameter
Go to the Menu screen / Setup. Select 'Tire diameter' by pressing the + and - button (10/12), and
confirm with the left toggle button (11). In first field, press the + or - button (10/12) to scroll to the
numbers 0-9 to the desired number. Press the left toggle button (11) to confirm the selection and
to jump to the next field. Repeat these steps for the next 3 fields.

3.6 Removing and installing the DS3 Display

To remove the DS3 Display from the bike, turn the display counter-clockwise until
it comes off from the holder. To install the DS3 Display, hold the Display in a 90°
angle above the holder, lower it into the holder and turn it clockwise until it clicks.
EN-15
