3. Instructions for Use

There are two types of controllers: ' RIDE+ Pro' and 'DS3 Display with RC3 Remote.

3.1 RIDE+ Pro controller

• 1. Speed indication • 2. Battery charge level • 3. '+' button • 4. Distance, Odometer, Chronometer,
Average speed, Clock • 5. '-' button • 6. Current assistance level • 7. Current generation level • 8. Mode-
switch button • 9. On/Off
*WARNING. If the Service Indication (a steady or blinking wrench symbol) is visible on the display, refer
immediately to paragraph 6.1 for instructions.
• Switching system On/Off
Press any of the two top buttons briefly to switch the system
On. The battery pack will beep four times, the system will
perform a short self-check (shown on the display as a
countdown in the 'speed'-field), and the system will activate
(switch to 'On'). As soon as the system is 'On', the screen will
display and each function will be shown next to its
corresponding button.
To switch the system Off, press the
will beep five times. Riding with the system 'On' in level 0 is the
same as riding with the system 'Off'. If the bike is left with the
system on, it will automatically switch Off after about 10 minutes.
• Changing the position of the buttons
Normally, the On/Off button
button are on the right, and the '+' and '-' buttons on the left.
The functionality of the buttons can be swapped right-to-left.
The code to access this is 2009. More information about
programming via the controller can be found later in this
manual.
• Assistance
When the motor provides power, the bicycle is in assistance
mode. There are four levels of assistance. The level of
assistance is shown by the arrows at the bottom of the display.
10 11
9
8
7
button • 10. Light indicator, On or Off • 11. Service Indication*.
button. The battery pack
and the mode-switch
i
nstructions for
1 2
6
u
se
3
4
5
EN-10
