Q
uick start

1.3 Charging

• Power supply
The battery pack can be charged using the power supply, on the bike or removed from the bike.
NOTICE.
When not in use, charge a battery pack at least once every six months
(refer to paragraph 3.9 and 3.10 for detailed instructions).
• Charging the battery pack
1. Turn the system Off.
2. Connect the connector of the power supply to the charging port
of the battery pack and connect the power supply to the power outlet.
WARNING. Replace a damaged power cable immediately to prevent an electric shock.
3. The battery pack will emit beeps and then the charging port will turn orange. When the battery
pack is full, the charging port will turn green. To stop charging, just disconnect both connectors.
Battery packs with the round charging connector can be left connected to the power indefinitely.
The power supply electronics will take care of the correct charging procedure. However, you will
save energy by disconnecting the power supply when the light in the charging port has turned
green.

1.4 Rear rack battery packs

• Removing the battery pack
- Switch Off the system before removing the battery pack.
- Insert the key in the lock, twist the key clockwise.
- Now slide the battery pack rearwards out of the rear rack.
- After you remove the battery pack, don't forget to take the keys out of the lock.
• Placing the battery pack
- Turn the key of the lock anti-clockwise and slide the battery pack into the rear rack, connector side first.
- Make sure the battery pack engages the rail.
- Slide all the way forward, pushing through a slightly higher resistance at the end as the connector
engages. Take the key out.
Do not ride the bike with the lock open.
EN-7
GREEN/ORANGE
