s. i n
Virtual instrument
inputs
Inputs IN
Bit 4
Ex: 1
Set code 24 in S.in. to manage serial line AN and
IN
• InP
InP
Input settings
sp. r
Def. remote setpoint
typ.
Probe type, signal, enable custom linearization,
and main input scale
Type Probe type without decimal point
Sensore:
0 TC J °C
1 TC J °F
2 TC K °C
3 TC K °F
4 TC R °C
5 TC R °F
6 TC S °C
7 TC S ° F
8 TC T °C
9 TC T °F
10 TC B °C
11 TC B °F
12 TC E °C
13 TC E °F
14 TC N °C
15 TC N °F
16 L-GOST °C
17 L-GOST °F
18 TC U °C
19 TC U °F
20 TC G °C
21 TC G °F
22 TC D °C
23 TC D °F
24 TC C °C
25 TC C °F
26 Ni-Ni18Mo °C
27 Ni-Ni18Mo °F
28 TC
29 TC
30 PT100 °C
31 PT100 °F
32 JPT100 °C
33 JPT100 °F
34 PTC °C
35 PTC °F
36 NTC °C
37 NTC °F
38 0...60 mV
39 0...60 mV
40 12...60 mV
41 12...60 mV
42 0...20 mA
43 0...20 mA
44 4...20 mA
45 4...20 mA
46 0...10 V
47 0...10 V
48 2...10 V
49 2...10 V
50 0...5 V
51 0...5 V
52 1...5 V
53 1...5 V
54 0...1 V
55 0...1 V
56 200mv..1V
57 200mv..1V
58 Cust10 V-20mA
59 Cust10 V-20mA
60 Cust 60mV
61 Cust 60mV
62 PT100-JPT
63 PTC
64 NTC
For custom linearization:
- LO signal is generated with variable below Lo.S or at minimum calibration
value
- HI signal is generated with variable above Lo.S or at maximum calibration
value
0 ... 31
PV AL3 AL2 AL1
3 2 1 0
1 0 0 0
Val. Type of remote setpoint Absolute Relative
0 Digital Absolute
(from serial line)
1 Digital Reletive to
(from serial line) local setpoint
+2 set gradient in digit / sec
with decimal point
TC
0/1000 0.0/999.9
32/1832 32.0/999.9
0/1300 0.0/999.9
32/2372 32.0/999.9
0/1750 0.0/999.9
32/3182 32.0/999.9
0/1750 0.0/999.9
32/3182 32.0/999.9
-200/400 -199.9/400.0
-328/752 -199.9/752.0
44/1800 44.0/999.9
111/3272 111.0/999.9
-100/750 -100.0/750.0
-148/1382 -148.0/999.9
0/1300 0.0/999.9
32/2372 32.0/999.9
0/600 0.0/600.0
32/1112 32.0/999.9
-200/400 -199.9/400.0
-328/752 -199.9/752.0
0/2300 0.0/999.9
32/4172 32.0/999.9
0/2300 0.0/999.9
32/4172 32.0/999.9
0/2300 0.0/999.9
32/4172 32.0/999.9
0/1100 0.0/999.9
32/2012 32.0/999.9
CUSTOM CUSTOM
CUSTOM CUSTOM
-200/850 -199.9/850.0
-328/156 2 -199.9/999.9
-200/600 -199.9/600.0
-328/1112 -199.9/999.9
-55/120 -55.0/120.0
-67/248 -67.0/248.0
-10/70 -10.0/70.0
14/158 14.0/158.0
-1999/9999 -199.9/999.9
Custom scale Custom scale
-1999/9999 -199.9/999.9
Custom scale Custom scale
-1999/9999 -199.9/999.9
Custom scale Custom scale
-1999/9999 -199.9/999.9
Custom scale Custom scale
-1999/9999 -199.9/999.9
Custom scale Custom scale
-1999/9999 -199.9/999.9
Custom scale Custom scale
-1999/9999 -199.9/999.9
Custom scale Custom scale
-1999/9999 -199.9/999.9
Custom scale Custom scale
-1999/9999 -199.9/999.9
Custom scale Custom scale
-1999/9999 -199.9/999.9
Custom scale Custom scale
-1999/9999 -199.9/999.9
Custom scale Custom scale
-1999/9999 -199.9/999.9
Custom scale Custom scale
CUSTOM CUSTOM
CUSTOM CUSTOM
CUSTOM CUSTOM
s. 0 v
Virtual instrument
Outputs
Bit
Ex:
set code 19 in S.Ou. to manage serial line OUT1, OUT2
and OUTW.
s. U . i
Virtual instrument user
Interf. LED KEYB
1/2/3
Bit 7 6
Ex: 1
If you want to manage KEYB and DISH from serial line, set code 80 in
S.U.I.
S, R range 0...1750°C; error < 0.2% f.s. (t > 300°C) / for other
range; error < 0.5% f.s.
T error < 0.2% f.s. (t > -150°C)
B range 44...1800°C; error < 0.5% f.s. (t > 300°C) / range
44,0...999,9; error < 1% f.s. (t > 300°C)
U range -99,9...99,9 and -99...99°C; error < 0.5% f.s. / for other
Max. non-linearity error for
thermocouples (TC),
range; error < 0.2% f.s. (t > -150°C)
resistors (PT100) and
G error < 0.2% f.s. (t > 300°C)
thermistors (PTC, NTC).
D error < 0.2% f.s. (t > 200°C)
C range 0...2300; error < 0.2% f.s. / for other range;
The error is calculated as
deviation from theoretical error < 0.5% f.s.
value and is expressed as
percentage of full scale (in
NTC error < 0.5% f.s.
°C).
Tc: J, K, E, N, L
JPT100 and PTC
PT100 scale -200...850°C
Precision better than 0,2% f.s. at 25°C
In range 0...50°C:
• Precision better than 0,2% f.s. in range -200...400°C
• Precision better than 0,4% f.s. in range +400...850°C
(where f.s. refers to range -200... +850°C)
Digital filter on input
flt
(if = 0 excludes averaging filter on
sample value)
fld
Digital filter on input
display
dp. s
Decimal point position for
input scale
lo. s
Minimum limit of main
input scale
xi. s
Maximum limit of main
input scale
ofs.
Offset correction
of main input
ft. 2
Digital filter
aux. input
23
0 ... 31
outputs
OUTW OUT4 OUT3 OUT2
4 3 2 1
1 0 0 1
0 ... 63
interface
DISL DISH LED LED
OUT4 OUT3 OUT2
5 4 3 2
0 1 0 0 0
error < 0,2% f.s.
error < 0,2% f.s.
0.0 ... 20.0 sec
0 ... 9.9
scale points
dP_S Format
0 xxxx
1 xxx.x
2 xx.xx (*)
3 x.xxx (*)
(*) not available for TC, RTD,
PTC and NTC scales
min...max input range
selected in tyP
min...max input range
selected in tyP
-999 ... 999
scale points
0.0 ... 20.0 sec
OUT1
0
1
LED LED
OUT1
1 0
