11.5 Starting up with the mowing unit switched off
(Fig. 23, 25)
Attention! Only change gear when the vehicle is
at a standstill.
1. With "tortoise" low engine speed, depress the
brake pedal (13) completely and release the lock-
ing brake (9).
2. Slowly release the brake pedal (13) so that the gas
pedal (8a) so that the petrol lawn tractor starts moving.
3. Push the speed lever (12) in the direction of the
"Hare" to accelerate.
4. In order to stop the device, release the gas pedal
(8a) and depress the brake pedal (13).
11.6 Mowing
m WARNING!
Danger of accident when reversing!
Be aware of the rear environment when reversing!
- Reverse only if necessary!
11.6.1 Setting the cutting height (Fig. 24)
m Attention! The cutting height may only be ad-
justed when the mowing unit is shut off.
Set the cutting height depending on the actual length
of the lawn. Carry out several passes so that a maxi-
mum of 4 cm of lawn is removed at a time.
1. Pull the cutting height adjustment lever (11) to-
wards the driver's seat (1) and lock it into the de-
sired cutting height.
2. 7 different cutting heights can be set.
IMPORTANT: For transport, the cutting tool must al-
ways be placed in the highest position (level 7).
11.6.2 Mowing/starting up with the mowing unit
switched on (Fig. 25)
m WARNING!
Risk of injury and damage!
Objects can be ejected and may hit and injure per-
sons. Solid objects can damage the product.
In addition, small stones or other objects can be
ejected at least 15 meters. This can damage cars,
houses, and windows.
- When mowing, keep a distance of 30 metres be-
tween bystanders or animals.
- Do not remove objects from footpaths etc. with the
product.
NOTE!
Risk of damage!
If the product is not cleaned regularly, grass/weed
residues can get caught beneath the mowing unit
cover. This can affect the performance of the product
and cause damage in the long run.
- Clean the product thoroughly after each use.
Attention! Only change gears when the vehicle is
at a standstill.
1. At "Tortoise" low speed, engage the parking brake (9).
2. Pull the PTO knob (5) all the way out to switch on
the mower.
3. With "tortoise" low engine speed, depress the
brake pedal (13) completely and release the lock-
ing brake (9).
4. Slowly release the brake pedal (13) so that the gas
pedal (8a) so that the petrol lawn tractor starts moving.
5. Push the speed lever (12) in the direction of the
"Hare" to accelerate.
6. In order to stop the product, release the gas pedal
(8a) and depress the brake pedal (13).
11.6.3 Reversing with the mowing unit switched
on (Fig. 26)
m WARNING!
Danger of accident when reversing!
Be aware of the rear environment when reversing!
Attention! Only change gears when the vehicle is
at a standstill.
1. At "Tortoise" low speed, engage the parking brake
(9).
2. Turn the ignition key to the "ROS" (
sition.
3. Pull the PTO knob (5) all the way out to switch on
the mower.
4. With "tortoise" low engine speed, depress the
brake pedal (13) completely and release the lock-
ing brake (9).
5. Slowly release the brake pedal (13) so that the
gas pedal (8b) so that the petrol lawn tractor starts
moving.
6. Push the speed lever (12) in the direction of the
"Hare" to accelerate.
7. In order to stop the product, release the gas pedal
(8b) and depress the brake pedal (13).
11.6.4 Working on slopes (Fig. 36)
m WARNING!
Danger due to errors when driving on slopes!
Take special care when driving on slopes! There is no
"safe" slope. Pay particular attention to the following
safety instructions!
• If the wheels should spin or if the vehicle gets stuck
when climbing a slope, disengage the mowing unit
and attachment devices. Then slowly descend and
leave the slope in a straight direction!
• A full collection basket increases the risk of the pet-
rol lawn tractor tipping over due to its weight!
• On slopes, the cutting path should be made per-
pendicular to the slope. It is possible to prevent the
petrol lawn tractor from slipping by lifting it upwards
at an angle.
