Scheppach WOODSTER TMR452-98H-RD Originalbetriebsanleitung Seite 39

• before checking, cleaning or working on the petrol
lawn tractor,
• if the mowing blade encounters a foreign object.
Look for damage to the machine and cutting tool
and have the necessary repairs carried out before
starting again,
• if the device starts to vibrate unusually strongly. Im-
mediate review is required.
• when leaving or transporting the device.
Residual risks and protective measures
Negligent use of personal protective equipment
(PPE)
Careless use or omission of personal protective
equipment may result in serious injury.
- Wear prescribed protective equipment.
Human behaviour, misconduct
- Always concentrate fully on all work.
m Residual risk can never be ruled out.
Danger from noise
Hearing damage
Prolonged unprotected work with the device may
cause hearing damage.
- Always wear hearing protection as a matter of
principle.
Behaviour in an emergency
In case of an accident, initiate the necessary first aid
measures and seek medical assistance as quickly as
possible.
7. Technical data
Type of engine
Displacement
Idle speed
Power
Fuel
CO output
2
Tank capacity / petrol
Engine oil
Oil tank capacity
Cutting height
adjustment
Collection basket
capacity
Cutting width
Cut height
4-Stroke engine / air
cooled
452 cm³
1800 +/-100 rpm
9.2 kW/ 12.5 PS
Regular grade petrol/
lead-free max. 10%
bioethanol
903.8 g/kWh
7.5 l
SAE 30 / 10W30
1.2 l
7-level
245 l
98 cm
30 - 90 mm ±5 mm
www.scheppach.com
Weight (unfuelled and
fully assembled)
Driving speed v
Reverse driving speed
Approved wheels
Front wheel (20000142)
Air pressure front
wheels
Rear wheel (20000138)
Air pressure rear wheels
Protection class LED
Spark plug
Electrode gap
Battery
Rated voltage
Capacity
Type
Subject to technical changes!
The noise levels have been determined in accord-
ance with EN ISO 3744:1995.and ISO 11094:1991.
Sound pressure level L
PA
Sound power level L
WA
Measurement uncertainty K
Wear hearing protection.
Exposure to noise can cause hearing loss.
If necessary, adhere to rest periods and limit the du-
ration of work to the bare minimum.
Vibration a (body)
h
Vibration a
h
(Hand - arm)
Measurement uncertainty K
Keep the noise level and vibration to a minimum!
• Only use faultless products.
• Maintain and clean the product at regular intervals.
• Adapt your working methods to the product.
• Do not overload the product.
• Have the product checked if necessary.
• Switch the product off if it is not in use.
• Wear protective gloves.
In the case of extended working periods, the operat-
ing personnel may suffer circulatory disturbances in
their hands (vibration white finger) due to vibrations.
200 kg
10 km/h
6 km/h
15 x 600-6 (15")
1.5 +/-0.15 bar
18 x 850-8 (18")
1.8 +/-0.15 bar
IP65
F7TC/F7RTC
0.7-0.8 mm
12 V
18 Ah
Lead acid
77.4 dB
98 dB
1.81 dB
1.263 m/s
2
per
EN 1032:2003+A1:2008
2.866 m/s
2
per
EN 1032:2003+A1:2008
1.5 m/s
2
GB | 39
