13.2.6 Replacing the fuse (28a) (Fig. 35)
The electric start is protected by a 20A fuse (28a).
Never use another fuse and never bypass it.
1. Open the bonnet (6) by lifting it forward.
2. Open the fuse holder (28).
3. Remove the defective fuse (28a) from the holder
(28).
4. Insert a new fuse (28a).
5. Close the fuse holder (28).
14. Repair & ordering spare parts
After repairs or maintenance, make sure that all safe-
ty-related parts are installed and are in perfect con-
dition. All parts which may cause injury must be kept
where they are inaccessible to children or others.
Attention: According to the German Product Liabili-
ty Act, no liability is accepted for damage caused by
improper repairs or by not using original spare parts.
Such work should be performed by a customer ser-
vice centre or an authorised specialist. The same ap-
plies to accessory parts.
Spare parts and accessories can be obtained from
our Service Centre. To do this, scan the QR code on
the front page.
Connections and repairs
Connections and repair work on the electrical equip-
ment may only be carried out by electricians.
Please provide the following information in the event
of any queries:
• Type of current for the engine
• Machine data - type plate
• Motor data - type plate
Important note in the case of repairs:
For return delivery of the product for repair, please en-
sure for safety reasons that it is free of oil and fuel
when it is sent to the service centre.
14.1 Ordering spare parts
Blade information
TMR452-98H-SD (59112116903)
Manufacturer:
Blade code:
Blade - Article no.:
TMR452-98H-RD (59112112903)
Manufacturer:
Blade code:
50 | GB
Ducar
DJ831410
59112116001
Ducar
DJ831253 (left blade)
DJ831254 (right blade)
www.scheppach.com
Blade - Article no.:
Approved wheels
Rear wheel 18"
Article no.:
Front wheel 15"
Article no.:
WARNING! Danger of injury! With accessories as
well as wearing parts and replacement parts use
only original parts.

14.2 Service information

With this product, it is necessary to note that the follow-
ing parts are subject to natural or usage-related wear,
or that the following parts are required as consumables.
Wearing parts*: Spark plug, air filter, fuel filter, mow-
ing blade, V-belt, fuse, tyres
* may not be included in the scope of delivery!

15. Storage

Attention: Clean and maintain the product before
each storage.
m WARNING!
Danger of injury!
After switching the engine off, the blade continues to
run for a few seconds. If you touch the rotating parts,
you may cut yourself.
• Wait until the blade comes to a standstill.
• Do not stop the blade with your hand.
• Wear protective gloves.
• Remove the spark plug connector (27) from the
spark plug (27a) to prevent unintentional starting of
the engine when switching off or parking the product.
• Activate the locking brake (9).
• Keep the blade away from your feet.
m DANGER!
Risk of fire and explosion!
Storing the product near potential sources of ignition
can result in a fire or an explosion. This can lead to
severe burns or death.
- Eliminate possible sources of ignition, such as fur-
naces, hot water boilers with gas, gas dryers, etc.
NOTE!
Risk of damage!
If the product is not stored properly, the engine can
be damaged.
59112112001
(left blade)
59112112002
(right blade)
20000138
20000142
