Scheppach MFH5200-4P Originalbetriebsanleitung Seite 50

2. Adjust the length of the strap so that the carabiner
hook (43a) is approx. one hand-width beneath the
right hip.
3. Attach the carabiner hook (43a) to the lifting eye (2).
4. Allow the product to settle.
Notes:
• The product may just touch the floor with the tool at-
tachment in a normal working position.
• Check that the shoulder strap is in a comfortable posi-
tion to make it easier for you to hold the product.
• In an emergency, the safety tab (43b) on the carrying
strap (43) can be pulled. The product then immediate-
ly detaches from the carrying strap (43) and falls to
the floor.
WARNING
Check the safety tab regularly before each start-up!
WARNING
Danger of injury!
If the carrying strap is not released in time in an emer-
gency, serious injuries may result!
10 Operation
ATTENTION
Always make sure the product is fully assembled
before commissioning!
ATTENTION
Make sure that the ambient temperature does not ex-
ceed 50°C and does not fall below -20°C during work.
DANGER
Danger of injury!
If the product is jammed, do not try to pull the product
out by using force.
– Switch off the engine.
– Use a lever arm or wedge to get the product free.
WARNING
Check the safety equipment regularly before each start-
up. Faulty safety equipment can cause serious injuries!
Note:
• Wear personal protective equipment when using the
product:
Hearing protection, eye protection (visor or goggles),
head protection and cut-resistant work clothing.
10.1 Switching the product on/off
(Fig. 1, 14)
WARNING
Danger of injury due to kickback!
– Never use the product one-handed!
50 | GB
DANGER
Danger of poisoning!
Only use the product outdoors and never in closed or
poorly ventilated rooms.
Note:
Before switching on, make sure that the product does not
touch any objects.
When using the brush cutter:
1. Remove the transport protection (16a) from the cutting
blade (16).
When using the pole-mounted pruner:
1. Check that there is saw chain oil in the oil tank (23).
2. Fill with chain oil before the oil tank (23) is empty (see
9.1).
3. Pull the guide bar and chain guard (22) off the chain-
saw guide bar (20).
When using the hedge trimmer:
1. Pull the blade guard (29) off the cutter bar (28).
10.1.1
ATTENTION
– Do not let the pull starter whip back in. This can re-
sult in damage.
– In case of cool weather, it may be necessary to re-
peat the starting process numerous times.
NOTE
Only use the fuel pump "primer" when the
engine is cold!
NOTE
If the engine is being started for the first time, several
tries are required to start until the fuel has been deliv-
ered from the tank to the engine.
ATTENTION
Never place a foot on the product or kneel on it.
Notes:
• The speed can be steplessly controlled by the throttle.
The further you press the throttle, the higher the
speed.
• Loosening the throttle brings the engine back into
idling and the tool attachment stops. The tool attach-
ment must not rotate or move while idle!
• Hold the product with both hands during the work.
Grasp both handles.
10.1.1.1
1. In colder temperatures, press the fuel pump "primer"
(44) ten times.
This makes it easier to start the engine.
2. Fold the foot (45) up
www.scheppach.com
Starting the engine
When the engine is cold
.
