• Secure the tool well during trans-
port to prevent damage to the tool
and injuries.
• Only use accessories recom-
mended by PARKSIDE. Unsuit-
able accessories may cause elec-
tric shock or fire.

Residual risks

There will always be residual risks
even if you operate this device ac-
cording to the instructions. The fol-
lowing hazards may occur in connec-
tion with the type and design of this
device:
• Eye damage if no suitable eye pro-
tection is worn.
• Hearing damage if suitable ear pro-
tection is not worn.
• Health injuries resulting from the
effect of hand/arm vibration in the
event that the tool is used over a
longer period of time or is not used
and maintained properly.
• Cutting injuries
WARNING! Danger due to elec-
tromagnetic field generated while the
tool is in operation. Under certain cir-
cumstances, this field may negat-
ively affect active or passive med-
ical implants. In order to reduce the
danger of serious or fatal injuries, we
recommend that individuals who wear
medical implants should consult their
doctor and the manufacturer of the
implant before operating the tool.

Preparation

WARNING! Risk of injury due to
unintentional start-up. Only insert
the battery into the device once the
device is fully prepared for use.

Control elements

Familiarise yourself with the operating
elements before using the device for
the first time.
• Charge level indicator button on
the device (27)
• Displaying the charge level of
the battery
• On/Off switch (31)
• Switching on: Press
• Switching off: Release
• Switch lock (32)
• Locks the on/off switch against
unintentional operation.
• Unlocking: Press
• Lever (43)
Locks/unlocks the angle adjust-
ment of the hedge trimmer attach-
ment
• Lock (46)
Locks/unlocks the angle adjust-
ment of the pruner attachment

Attaching the tubular shaft

Notes
• Before mounting, remove the pro-
tective cap(s) from the front tubular
shaft (2).
• Tighten the wing nut (3) until you
cannot feel any more play on the
front tubular shaft (2)! Applying
maximum manual force will dam-
age the tubular shaft.
Procedure (Fig. A)
1. Undo the wing nut (3).
2. Pull the lock (8) outward and turn
the lock left or right as far as it
goes.
3. Slide the front tubular shaft (2)
onto the tubular shaft on the gear-
box housing (4).
4. Pull the lock (8) outward and turn
the lock back to its original posi-
tion.
