Overview
The illustrations for the
device can be found on
the front and back fold-
out page.
1 Saw chain
2 Front tubular shaft
3 Wing nut
4 Tubular shaft on device housing
5 Auxiliary handle
6 Eyelet
7 Leg protection
8 Lock (Tubular shaft)
9 Chain guard
10 Blade guard
10a Blade guard clip
11 Safety cutter bar
12 3-blade steel cutter
13 Transport protection
14 Protective cover
15 Line cutter
16 Protective cover extension
17 Spool cap
18 Organic saw chain oil
19 Double shoulder strap
20 Hip protector
21 Hex key (4 mm)
22 Hex key (5 mm)
23 Combination tool
24 Screwdriver
25 Battery
26 Charger
27 Charge level indicator button on
the device
28 Charge level indicator on the
device
29 Handle
30 Storage
31 On/Off switch
32 Switch lock
(Fig. B)
33 Grip screw
(Fig. C)
34 Nut (Sprocket cover)
35 Sprocket cover
36 Blade bar
37 Blade bar bolt
38 Sprocket
39 Oil passage
40 Chain tensioner screw
(Fig. D)
41 Oil tank cap
42 Adjusting screw
(Fig. E)
43 Safety lever
44 Handle for adjusting the cutter
bar
45 Locking lever
(Fig. F)
46 Lock (Pruner attachment)
(Fig. G)
47 Click fastener
48 Carabiner
49 Screw (Eyelet)
(Fig. H)
50 Cover
51 Screw (Protective cover)
52 Hexagon socket screw
(Fig. I)
53 Line outlet loop
54 Spool
55 Fastener
(Fig. J)
56 Clamping disk
57 Nut
