USER`S MANUAL
Other Standard Hardware
5.25-inch format (12.7mm height) fixed module with 24X speed.
• CD-ROM
• DVD ROM
5.25-inch format (12.7mm height) fixed module. (Optional)
• Keyboard
87-key touch-type QWERTY keyboard with embedded numeric
Keypad.
• Pointing
TouchPad with 2 buttons.
Device
PC Card
• PCMCIA
O2Micro OZ 6812 / 6912 controller with Zoomed Video Capability.
Controller
• Features Single slot for TYPE II / III PC Cards with Card Bus 1.0 interface,
having hot insertion and removal supported, enabling connection
to peripherals as multimedia communications.
Ports
• VGA Port
One 15-pin CRT connector
• Audio Port One stereo line-out jack & One microphone-in jack
• Infrared Port One FIR LED
• Parallel Port One 25-hole parallel connector (ECP / EPP)
• Serial Port One 9-pin serial connector (16550A / FIFO)
• USB Port
One USB connector
• PS/2 Port One 9-pin connector
• Modem Port
One standard phone jack (RJ-11)
• LAN Port One standard network connector (RJ-45)
• Power Port
One DC-in connector
Power
• Main Battery Ni-MH 10-cell, 48.0 Whrs (total capacity), 12.0V, 4000mAh.
Li-Ion 8-cell, 47.4 Whrs (total capacity), 14.8V, 3200mAh.
• AC Adapter 100~240V, 50~60Hz, 20/60W.
• Recharge
System OFF: 3~4 HR (100%)
System ON: 8~10 HR (100%)
• Other Low Battery Warning
Features Suspend / Resume capability
A-4
