USER`S MANUAL

System at a Glance

Top View

1
2
8
Warning:
Do not place any
heavy objects on
the top of notebook
when the latches
are on. That may
damage the
display.
1-4
6
7
Fn
9
1. LCD Latches
The left and right LCD latches lock/unlock the LCD panel.
2. LCD Display Panel
This notebook is equipped by the liquid crystal display with
XGA and SXGA resolution.
11
3
4 5
1
10
