Installing and Removing the Battery Pack

Carefully observe the illustration for this operation.
To Detach the Battery Pack:
3-4
1. Position the notebook rear-side up on a flat and secured
surface.
2. Locate the battery latches. Slide the locked latch toward
direcrion 1 shown by the arrow in the following figure and
hold.
3. Continue holding the latches in the releasing position,
and pull out the battery's module hard case toward
direction 2.
4. Lift the battery pack
out of the battery
compartment
as the right diagram.
