5. CPU Heatsink/Fan Bay
The bay is where the CPU be installed.
6. Battery Latches
The battery latches locks or releases the battery pack.
7. Battery Pack
The battery pack is a built-in power source for the notebook.

LED Status Indicators

The indicators under the LCD display panel, show as follow,
inform you the current operating status of your notebook. As a
certain function is enabled, the represented indicator will
illuminate. The icons or symbols are captured as follow and
descipted in detail.
Section 1 GETTING TO KNOW THE BASICS
1-11
