4. PS/2 Port
The notebook is designed to use one pointing device at once
time. This is where you connect a external PS/2-compatible
devices such as a mouse or keyboard.
5. Stereo Microphone Jack
The stereo microphone jack (3.5-mm diameter) is where you
connect a microphone. To avoid the malfunction, please
disable the built-in Microphone.
6. Stereo Headphone Jack
The stereo headphone jack (3.5-mm diameter) is where you
connect the headphones or external speakers. With this
function on, please disable the internal built-in speakers.
7. External VGA Port
The 15-pin VGA analog port is for connecting the external
CRT monitor or projector.
8. Serial Port
This is where you connect a serial device via a 9-pin serial
(RS-232) cable.
9. Parallel Port
The 25-hole parallel port is primarily where the printer signal
cable attached. (The FDD module with the supplied parallel-
port cable can be plugged into this port also.)
10. LAN Port
The port connects to a network hub via the RJ-45 cable and
also conforms to 10Base-T and 100Base-TX transmission
protocols.
Section 1 GETTING TO KNOW THE BASICS
1-7
