Expanding the Hard Disk Drive

To replace the hard disk drive, do the following:
1. Turn OFF the computer. Unhook the AC cord and all
2. Place your hand on a large metal object momentarily to
3. Locate the hard disk drive module on the bottom of the
4. Release the fixing screw-A locked the HDD bay cover.
5. Remove the HDD bay cover as the shown diagram.
6. Now the mental tray protected HDD module and the
7. Release the two fixing screws, B and C, securing the
8. Release the two fixing screws, D and E, securing the
Hard Disk
Drive Module
Connector
Section 4 UPGRADING YOUR NOTEBOOK
cables/devices attached to the notebook.
discharge any static electricity.
notebook.
fixing screws, B and C, reveal.
mental HDD tray and HDD module.
mental HDD tray and the unite.
Fixing Screw-B
HDD Bay Cover
Fixing Screw-A
Fixing Screw-C
Fixing
Screw-E
Mental
Tray
Fixing
Screw-D
