Removing the DIMM Module In The Expansion Socket

To remove the memory module, do the following:
1. Follow steps 1~7 in the above section, Installing the
DIMM Module In The Memory Socket .
2. Press out on the latches located on both edges of the
expansion socket at the same time. The DIMM should
pop up to an angle of 30 degree.
3. Remove the DIMM from the expansion socket. Be sure
to save the DIMM for future use.
4. Put the keyboard back to its original face-up position. Be
aware of the flexible PCB connected to the keyboard.
The keyboard should now be locked by the spring-loaded
latches.
5. Power on the notebook and when it starts up note if the
memory count has decreased to the original memory
capacity.
You have completed the removal of the DIMM.
Section 4 UPGRADING YOUR NOTEBOOK
Illustration 4-7
4-11
