Note:
Notice the notches
on the DIMM. The
notches should fit
nicely with the
socket.
You have just completed the memory upgrade.
9. Pull the DIMM module out of the memory socket. Be
sure to reserve the DIMM for the future use.
10. Install the DIMM module into the memory socket. The
DIMM will only fit in one orientation. Slide the DIMM at
an angle of approximately 30 degrees into the empty
memory socket. Then press it firmly so that the contact
edge is driven into the receiving socket.
DIMM Module
11. Pivot the DIMM until the latches on both sides of the
socket snap into place. At the time, you will feel a click.
12. Put the keyboard back to its original face-up position. Be
aware of the flexible PCB connected to the keyboard.
The keyboard should now be locked by the spring-loaded
latches.
Section 4 UPGRADING YOUR NOTEBOOK
Illustration 4-6
Memory Socket
Notch
4-9
