EN
e) Do not put anything on the top of the ice maker.
Installation clearance
To ensure proper ventilation for your ice maker, the front of the unit must be completely
unobstructed (at least 20CM free space). Allow at least 15 cm clearance at rear, and 5 cm of
two sides for proper air circulation. And allow about 50cm high space at top to fill water freely
from unit top when using manual water supply way and for proper air circulation. The
installation should allow the ice maker to be pulled forward for servicing if necessary. When
installing the ice maker under a counter, follow the recommended spacing dimensions shown
above. Place electrical and drain fixtures in the recommended locations as shown.
Choose a well-ventilated area with temperatures above 10℃ and below 32℃. This unit MUST
be installed in an area protected from some elements, such as wind, rain, water spray or drips.
The temperature of the water feeding into the ice maker should be between 5℃ and 25℃ for
proper operation.
ELECTRICAL REQUIREMENT & CONNECTIONS
WARNING
: THIS UNIT MUST BE EARTHED.
Plug into a grounding wall outlet.
Never remove the ground prong.
Use separate power supply or receptacle. Never use an adapter.
Never use an extension cord.
Failure to follow these instructions can result in death, fire, or
electrical shock.
Before you move your ice maker into its final location, it is important to make sure you have
the proper electrical connection.
It is recommended that a separate circuit, serving only your ice maker, be provided. Use
receptacles that cannot be turned off by a switch or pull chain. If the supply cord or plug to
top view (mm)
Electrical Shock Hazard
Side view (mm)
11
