7. Setting the product

7.1 Standard operating panel

Pos. Symbol Description
Grundfos Eye: The indicator light shows the
1
operating status of the product.
2 - Light fields for indication of the setpoint
3 Up/Down: The buttons change the setpoint.
Radio communication: The button enables radio
4 communication with the Grundfos GO and other
products of the same type.
Start/Stop: Press the button to make the product
ready for operation or to start and stop the product.
Start: If you press the button when the product is
stopped, the product starts if no other functions
5 with higher priority have been enabled.
Stop: If you press the button when the product is
running, the product always stops. When you press
the button, the stop icon appears at the bottom of
the display.
12
1
2
3
4
Stop
5

7.2 Setpoint setting

The setpoint must not be set higher than the pressure
which the pump can deliver.
If you change the outlet pressure, you must adjust the
precharge pressure in the diaphragm tank accordingly.
Set the desired setpoint of the pump by pressing
The light fields on the operating panel will indicate the setpoint set.
H : maximum head (see pump nameplate).
max
H
max
0

7.3 Start/stop of pump

Start the pump by pressing or by continuously pressing
the desired setpoint is indicated.
Stop the pump by pressing . When the pump is stopped, the
"Stop" text next to the button will be on. The pump can also be
stopped by continuously pressing
on.
If the pump has been stopped by pressing
free to operation by pressing
If the pump has been stopped by pressing
restarted by pressing .

7.4 Resetting of fault indications

A fault indication can be reset in one of the following ways:
• Briefly press or on the pump. This will not change the
setting of the pump. A fault indication cannot be reset by
pressing or if the buttons have been locked.
• Switch off the power supply until the indicator lights are off.
• With Grundfos GO.
or .
until
until none of the light fields are
, it can only be given
again.
, it can only be
