Connection terminals for inputs and outputs, FM 200. See the figure above.
Terminal Type
NC Normally closed contact
C1 Common
NO Normally open contact
NC Normally closed contact
C2 Common
NO Normally open contact
10 DI3/OC1
4 AI1
2 DI1
5 +5 V
6 GND
A GENIbus, A
Y GENIbus, Y
B GENIbus, B
3 GND
15 +24 V
8 +24 V
26 +5 V
23 GND
25 GDS TX
24 GDS RX
7 AI2
Function
Signal relay 1 (LIVE or PELV)
Signal relay 2 (PELV only)
Digital input/output, configurable.
Open collector: Maximum 24 V resistive or inductive.
External sensor.
Pressure sensor: Pressure signal, 0.5 to 3.5 V. Connect the
white wire to this terminal.
Digital input, configurable.
Digital input 1 is factory-set to be start or stop input where an
open circuit results in stop. A jumper has been factory-fitted
between terminals 2 and 6. Remove the jumper if digital input 1
is to be used as external start or stop or any other external
function.
Power supply to a potentiometer or sensor
Protective earth
GENIbus, A (+)
GENIbus, Y (GND)
GENIbus, B (-)
Protective earth
Power supply
Power supply
Power supply to a potentiometer or sensor.
Pressure sensor: Voltage supply, +5 VDC, PELV. Connect the
brown wire to this terminal.
Protective earth.
Pressure sensor: GND, 0 V. Connect the green wire to this
terminal.
Grundfos Digital Sensor output
Grundfos Digital Sensor input
External sensor.
Pressure sensor: Temperature signal, 0.5 to 3.5 V. Connect the
yellow wire to this terminal.
